F1352CC  | NEWFREN BMW F750/F850GS / F900R/F900XR 2016-24 Clutch Plates

F1352CC | NEWFREN BMW F750/F850GS / F900R/F900XR 2016-24 Clutch Plates


We have 2 in stock.
SKU : F1352CC

Regular price Rs. 9,690.00 Sale

Complete The Look

Description

The clutch facings of the Italian manufacturer Newfren are developed and manufactured with the latest technology. The company has been active in the accessories industry for two-wheelers since the late 50s and thus builds on many years of experience.

The products are asbestos-free and designed for long-lasting use under high loads. They offer optimum adhesion-even in the most severe conditions. In addition, Newfren stands for clutch sets perfectly adapted to the motorcycles and uses different materials depending on the intended use. The Ducati clutches are thus made of sintered metal or organic material depending on the use, applicable on the road or race track!

Technical features


Conduttore / Friction

Qty  9
Thickness  2,8
Nr. of edges  12
External Diameter  132,5
Internal Diameter  111,5


Condotto / Steel

Qty  7
Thickness  2,3
Nr. of teeth  34
External Diameter  132,5
Int diam. bottom teeth (mm)  104
Int diam. top teeth (mm)  96


Condotto / Steel

Qty  1
Thickness  2,3
Nr. of teeth  36
External Diameter  133
Int diam. bottom teeth (mm)  110,5
Int diam. top teeth (mm)  103

Fits On



Model Year Tipology
F GS (K80) 750 2019 - 2024
Clutch plates
F GS (K81) 850 2016 - 2024
Clutch plates
F GS ADVENTURE (K82) 850 2017 - 2024
Clutch plates
F R 900 2020 - 2024
Clutch plates
F XR 900 2020 - 2024
Clutch plates
