Functions

  • Push-button control for 4 or 5-button operation
  • Replacement of the vehicle fuses
  • Alarm system
  • Load-independent flasher relay
  • Hazard warning lights
  • Blinker as position light (adjustable)
  • Time-controlled blinker switch-off
  • Path-controlled turn signal deactivation (speedometer sensor required)
  • Parking light and headlight flasher integrated
  • Control of low beam and high beam with one button
  • Stop light modulator (8 adjustable modes)
  • Emergency stop light
  • Garage light
  • Fan run-on
  • Hyperbeam (200W high beam + low beam)
  • Starter relay for starter with magnetic switch (max. 30 A)
  • Intelligent switch-off of consumers at startup
  • Integrated, digital horn relay
  • Two configurable additional outputs AUX1 and AUX2
  • Complete wiring system diagnostic function
  • Defect detection of all light sources



Functions with the mo.ride app
  • Keyless-Go (ready to start when approached with a smartphone)
  • Tour log in mo.ride with fun factor, number of bends, top speed, etc.
  • Alarm events with date, time, vehicle on the ground, etc.
  • Setting the mode and sensitivity of the alarm system
  • Monitoring the battery voltage
  • Diagnosis of all inputs and outputs with currents and voltage
  • Defect detection of light sources
  • Rideassist: turn signal sound and errors as audio via helmet headset
  • Manual switching of outputs via smartphone (except starter)
  • Firmware updates at any location
  • Configuration of the setup menu
  • Vehicle management with information on maintenance tasks
  • All trips and messages in chronological order in the logbook
  • Display of parking position and Ping! to help with vehicle search
  • Secure, encrypted connection via Bluetooth® LE
  • ultra-low-power standby: low power consumption when stationary

Compatibility iPhone from iOS 15 / Android from 11 (availability may be limited) Further information at mo.ride.de

Technical data
  • Dimensions 90 x 53 x 30mm (L/W/H)
  • Waterproof, vibration-resistant - IP69
  • Weight approx. 180 g
  • Fastening 2 x M5 screw, distance 74mm
  • Operating voltage 6 V - 20 V
  • Operating temperature -20° to +80°C
Inputs
  • Ignition lock +12V or mo.lock
  • Turn signal left
  • Turn signal right
  • Light
  • Starter
  • Horn
  • Brake light
  • Kill
  • Side stand
  • LIN bus
  • AUX1
  • AUX2
Outputs
  • Turn signal left
  • Turn signal right
  • Low beam
  • High beam
  • Starter
  • Horn
  • Brake light
  • Ignition
  • AUX1 (Universal)
  • AUX2 (Universal)
