Description
The clutch facings of the Italian manufacturer Newfren are developed and manufactured with the latest technology. The company has been active in the accessories industry for two-wheelers since the late 50s and thus builds on many years of experience.
The products are asbestos-free and designed for long-lasting use under high loads. They offer optimum adhesion-even in the most severe conditions. In addition, Newfren stands for clutch sets perfectly adapted to the motorcycles and uses different materials depending on the intended use. The Ducati clutches are thus made of sintered metal or organic material depending on the use, applicable on the road or race track!
Technical features
Conduttore / Friction
| Qty | 9 |
| Thickness | 2,8 |
| Nr. of edges | 12 |
| External Diameter | 132,5 |
| Internal Diameter | 111,5 |
Condotto / Steel
| Qty | 7 |
| Thickness | 2,3 |
| Nr. of teeth | 34 |
| External Diameter | 132,5 |
| Int diam. bottom teeth (mm) | 104 |
| Int diam. top teeth (mm) | 96 |
Condotto / Steel
| Qty | 1 |
| Thickness | 2,3 |
| Nr. of teeth | 36 |
| External Diameter | 133 |
| Int diam. bottom teeth (mm) | 110,5 |
| Int diam. top teeth (mm) | 103 |
Fits On
